Tripp Lite SMART750TSU uninterruptible power supply (UPS) Line-Interactive 0.75 kVA 600 W 8 AC outlet(s)

Tripp Lite SMART750TSU uninterruptible power supply (UPS) Line-Interactive 0.75 kVA 600 W 8 AC outlet(s)

Tripp Lite SMART750TSU, Line-Interactive, 0.75 kVA, 600 W, Sine, 110 V, 120 V

Trade Prices

Distributor Product SKU Stock Updated Price
Anixter

750VA 600W UPSSMART TOWER BATTERY BACK UPDESKTOP AVR USB LCD

 10262935 Register free see stock
Arlington Industries

8-OUT LCD LINE INTERACTIVE TOWER UPS

 TRPSMART750TSU
BlueStar

EATON, 750VA 600W LINE-INTERACTIVE UPS - 8 NEMA 5-15R OUTLETS, AVR, 120V, 50/60 HZ, USB, RS-232, LCD, TOWER

 SMART750TSU

Related Products

Description

Tripp Lite SMART750TSU. UPS topology: Line-Interactive, Output power capacity: 0.75 kVA, Output power: 600 W. AC outlet types: NEMA 5–15R, Power plug: NEMA 5-15P, AC outlets quantity: 8 AC outlet(s). Typical backup time at full load: 4 min, Typical backup time at half load: 13 min. Form factor: Tower, Product color: Black, Housing material: Acrylonitrile butadiene styrene (ABS). Cables included: Serial, USB cable

Specifications

Power
Output frequency50/60 Hz
Output power600 W
Input operation voltage (min)110 V
Input operation voltage (max)120 V
Output operation voltage (min)110 V
Output operation voltage (max)120 V
Surge energy rating316 J
Maximum current10 A
Power factor0.8
Output power capacity0.75 kVA
Input frequency50/60 Hz
Ports & interfaces
Cable length59.1" (1.5 m)
USB portYes
Serial interfaceYes
AC outlets quantity8 AC outlet(s)
AC outlet typesNEMA 5–15R
Power plugNEMA 5-15P
USB 2.0 ports quantity1
Serial ports quantity1
USB port typeUSB Type-B
Performance
Audible alarm modesAlarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm
UPS topologyLine-Interactive
WaveformSine
Automatic Voltage Regulation (AVR)Yes
LED indicatorsYes
EMI/RFI noise filteringYes
Audible alarm(s)Yes
Features
Output frequency50/60 Hz
Country of originChina
Audible alarm modesAlarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm
UPS topologyLine-Interactive
WaveformSine
Automatic Voltage Regulation (AVR)Yes
Output power600 W
Input operation voltage (min)110 V
Input operation voltage (max)120 V
Output operation voltage (min)110 V
Output operation voltage (max)120 V
Surge energy rating316 J
Maximum current10 A
EMI/RFI noise filteringYes
Power factor0.8
Audible alarm(s)Yes
Output power capacity0.75 kVA
Input frequency50/60 Hz
Battery
Typical backup time at half load13 min
Typical backup time at full load4 min
Cold startYes
Design
Country of originChina
Form factorTower
LED indicatorsYes
Product colourBlack
Cable length59.1" (1.5 m)
Housing materialAcrylonitrile butadiene styrene (ABS)
Display typeLCD
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 90%
Storage relative humidity (H-H)0 - 90%
Technical details
Output frequency50/60 Hz
Packaging content
ManualYes
Cables includedSerial, USB cable
Weight & dimensions
Package width9.3" (236.2 mm)
Package depth19.5" (495.3 mm)
Package height11.7" (297.2 mm)
Weight23.1 lbs (10.5 kg)
Width5.5" (139.7 mm)
Package weight24.3 lbs (11 kg)
Height7.5" (190.5 mm)
Depth15" (381 mm)
Packaging data
ManualYes
Cables includedSerial, USB cable
Package width9.3" (236.2 mm)
Package depth19.5" (495.3 mm)
Package height11.7" (297.2 mm)
Package weight24.3 lbs (11 kg)
Logistics data
Country of originChina
Products per master (outer) case1 pc(s)
Master (outer) case width9.3" (236.2 mm)
Master (outer) case length19.5" (495.3 mm)
Master (outer) case height11.7" (297.2 mm)
Master (outer) case gross weight24.3 lbs (11 kg)
