Tripp Lite ECO650UPSM uninterruptible power supply (UPS) Standby (Offline) 0.65 kVA 325 W 10 AC outlet(s)

Tripp Lite ECO650UPSM uninterruptible power supply (UPS) Standby (Offline) 0.65 kVA 325 W 10 AC outlet(s)

Tripp Lite ECO650UPSM, Standby (Offline), 0.65 kVA, 325 W, Pure sine, 110 V, 120 V

Trade Prices

Distributor Product SKU Stock Updated Price
Anixter ECO SERIES 120V 650VA 325WENRGY-SVING STANDBY UPS W/USBMUTED ALARM & 8 OUT. 640219 Register free see stock
BlueStar TRIPP LITE, 650VA 325W UPS ECO GREEN BATTERY BACK UP 120V USB MUTED ALARM ECO650UPSM

Related Products

Description

Tripp Lite ECO650UPSM. UPS topology: Standby (Offline), Output power capacity: 0.65 kVA, Output power: 325 W. AC outlet types: NEMA 5-15R, Power plug: NEMA 5-15P, AC outlets quantity: 10 AC outlet(s). Typical backup time at full load: 1 min, Typical backup time at half load: 4.5 min. Form factor: Compact, Product color: Black, Housing material: Acrylonitrile butadiene styrene (ABS). Width: 4.33" (110 mm), Depth: 7.28" (184.9 mm), Height: 4.13" (104.9 mm)

Specifications

Power
Output frequency50/60 Hz
Output power325 W
Input operation voltage (min)110 V
Input operation voltage (max)120 V
Output operation voltage (min)110 V
Output operation voltage (max)120 V
Surge energy rating316 J
Maximum current15 A
Output power capacity0.65 kVA
ECO modeYes
Ports & interfaces
Cable length59.1" (1.5 m)
USB portYes
AC outlets quantity10 AC outlet(s)
AC outlet typesNEMA 5-15R
Power plugNEMA 5-15P
USB 2.0 ports quantity1
Modem (RJ-11) ports1
Ethernet LAN (RJ-45) ports1
Performance
UPS topologyStandby (Offline)
WaveformPure sine
LED indicatorsYes
EMI/RFI noise filteringYes
Surge protection featuresDigital Subscriber Line (DSL), Network, Telephone
Features
Output frequency50/60 Hz
Country of originVietnam
UPS topologyStandby (Offline)
WaveformPure sine
Output power325 W
Input operation voltage (min)110 V
Input operation voltage (max)120 V
Output operation voltage (min)110 V
Output operation voltage (max)120 V
Surge energy rating316 J
Maximum current15 A
EMI/RFI noise filteringYes
Surge protection featuresDigital Subscriber Line (DSL), Network, Telephone
Output power capacity0.65 kVA
ECO modeYes
Battery
Typical backup time at half load4.5 min
Typical backup time at full load1 min
Cold startYes
Design
Country of originVietnam
Form factorCompact
LED indicatorsYes
Product colourBlack
Cable length59.1" (1.5 m)
Housing materialAcrylonitrile butadiene styrene (ABS)
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 90%
Operating altitude0 - 120000" (0 - 3048 m)
Technical details
Output frequency50/60 Hz
Sustainability certificatesENERGY STAR
Compliance certificatesRoHS
Weight & dimensions
Package width5.67" (144 mm)
Package depth10.9" (275.8 mm)
Package height7.37" (187.2 mm)
Weight3.97 lbs (1.8 kg)
Width4.33" (110 mm)
Package weight4.41 lbs (2 kg)
Height4.13" (104.9 mm)
Depth7.28" (184.9 mm)
Packaging data
ManualYes
Cables includedUSB cable
Package width5.67" (144 mm)
Package depth10.9" (275.8 mm)
Package height7.37" (187.2 mm)
Package weight4.41 lbs (2 kg)
Logistics data
Products per master (outer) case8 pc(s)
Master (outer) case width11.5" (291.8 mm)
Master (outer) case length23.5" (596.9 mm)
Master (outer) case height15.9" (403.9 mm)
Master (outer) case gross weight37.3 lbs (16.9 kg)
Master (outer) case GTIN (EAN/UPC)10037332211078
Packaging content
ManualYes
Cables includedUSB cable
